Solar panels
Features:
1. High conversion efficiency based on leading innovative photovoltaic technologies;
2. High stabillity with guaranteed+/-3%power output tolerance, ensuring return on investment;
3. Beautiful appearance;
4. Sealed with high transparency low iron tempered glass, anti-aging EVA , high insulation TPT, with the anodizing (or plating finish);
5. Withstands high wind-pressure and snow load;
6. Easy to install.
Applications
1. On-grid utility systems;
2. On-grid commercial systems;
3. Off-grid ground mounted systems;
4. Our products are widely used in solar lighting, lamps, household electricity, traffic, communication, meteorological, building and photovoltaic power plants and other fields.
|
品名规格Specifications |
边框材质Frame Material |
边框尺寸 Frame Dimension (mm) | 实际功率(W) |
参考重量Approx Weight（KG) |
||
| 高(H) | 宽(W) | 厚度(TH) | ||||
| 9v3W | 铝合金 Aluminium Alloy | 160 | 200 | 16 | 3.5 | 0.19 |
| 6V10W | 铝合金 Aluminium Alloy | 230 | 340 | 18 | 10.5 | 0.64 |
| 18V10W | 铝合金 Aluminium Alloy | 230 | 340 | 18 | 10.5 | 0.64 |
| 12V20W | 铝合金 Aluminium Alloy | 420 | 340 | 18 | 20 | 1.27 |
| 18V20W | 铝合金 Aluminium Alloy | 330 | 510 | 18 | 20 | 1.27 |
| 18V30W | 铝合金 Aluminium Alloy | 470 | 510 | 25 | 30 | 1.89 |
| 18V40W | 铝合金 Aluminium Alloy | 535 | 515 | 25 | 40 | 2.53 |
| 18V50W | 铝合金 Aluminium Alloy | 680 | 515 | 30 | 50 | 3.16 |
| 18V60W | 铝合金 Aluminium Alloy | 820 | 515 | 30 | 60 | 3.55 |
| 18V70W | 铝合金 Aluminium Alloy | 760 | 670 | 30 | 70 | 4.6 |
| 18V80W | 铝合金 Aluminium Alloy | 830 | 670 | 30 | 80 | 5 |
| 18V100W | 铝合金 Aluminium Alloy | 1010 | 670 | 30 | 100 | 6.33 |
| 18V120W | 铝合金 Aluminium Alloy | 1190 | 670 | 30 | 120 | 6.5 |
| 18V150W | 铝合金 Aluminium Alloy | 1480 | 680 | 35 | 150 | 7.2 |
| 36v200W | 铝合金 Aluminium Alloy | 1300 | 990 | 40 | 200 | 10.5 |
| 30v250W | 铝合金 Aluminium Alloy | 1630 | 990 | 40 | 255 | 12 |
| 36v300W | 铝合金 Aluminium Alloy | 1940 | 990 | 45 | 310 | 15 |
