AGM Battery NPH Series
Features&Benefits
Computer optimized grid and plate design for high power output;
Battery case material is available in both HBO or flame retardant V0 (UL94);
High quality lead-tin-calcium alloy grids;
Usable in any orientation;
Computer optimized grid and plate design for high power output;
Battery case material is available in both HBO or flame retardant V0 (UL94);
High quality lead-tin-calcium alloy grids;
Usable in any orientation;
Applications
Office Machines and Computers, Telecommunications; UPS Equipment; Electrical facilities; Vending machine
Office Machines and Computers, Telecommunications; UPS Equipment; Electrical facilities; Vending machine
| Battery Type | Nominal Voltage (V) | Capacity Ah | Watts/cell | Dimension(±1mm) | Weight(±5%) | Terminal Type | ||||||||
| 10hr rate to 1.8V/cell | 15min rate to 1.67V/cell | Length | Width | Height | Total Height | (approx) kg | (approx) pound | |||||||
| mm | in | mm | in | mm | in | mm | in | |||||||
| NPH12-28W | 12 | 6 | 28 | 151 | 5.94 | 50 | 1.97 | 94 | 3.7 | 100 | 3.94 | 1.8 | 3.97 | F2 |
| NPH12-33W | 12 | 7.7 | 33 | 151 | 5.94 | 65 | 2.56 | 94 | 3.7 | 100 | 3.94 | 2.45 | 5.4 | F2 |
| NPH12-65W | 12 | 13.1 | 65 | 151 | 5.94 | 98 | 3.86 | 95 | 3.74 | 101 | 3.98 | 3.8 | 8.38 | F2 |
| NPH12-77W | 12 | 17 | 77 | 181 | 7.13 | 77 | 3.03 | 167 | 6.57 | 167 | 6.57 | 5.8 | 12.8 | F13 |
| NPH12-100W | 12 | 26 | 100 | 166 | 6.54 | 175 | 6.89 | 125 | 4.92 | 125 | 4.92 | 8.6 | 18.95 | F13 |
| NPH12-120W | 12 | 27 | 120 | 165 | 6.5 | 125 | 4.92 | 175 | 6.89 | 175 | 6.89 | 9.1 | 20.1 | F13 |
| NPH12-150W | 12 | 32 | 150 | 195 | 7.68 | 130 | 5.12 | 155 | 6.1 | 168 | 6.61 | 10.6 | 23.36 | F11 |
| NPH12-185W | 12 | 45 | 200 | 197 | 7.76 | 165 | 6.5 | 170 | 6.69 | 170 | 6.69 | 13.9 | 30.64 | F11 |
| NPH12-250W | 12 | 55 | 250 | 229 | 9.02 | 138 | 5.43 | 208 | 8.19 | 212 | 8.35 | 18.2 | 40.11 | F11 |
| NPH12-300W | 12 | 74.5 | 300 | 260 | 10.2 | 169 | 6.65 | 208 | 8.19 | 212 | 8.35 | 24.1 | 53.12 | F11 |
| NPH12-350W | 12 | 90 | 350 | 306 | 12.1 | 169 | 6.65 | 208 | 8.19 | 212 | 8.35 | 28.5 | 62.81 | F11 |
| NPH12-380W | 12 | 100 | 380 | 328 | 12.9 | 171 | 6.74 | 214 | 8.43 | 218 | 8.59 | 31 | 68.32 | F12 |
| NPH12-420W | 12 | 112 | 420 | 328 | 12.9 | 171 | 6.74 | 214 | 8.43 | 218 | 8.59 | 31.6 | 69.65 | F12 |
| NPH12-440W | 12 | 123 | 440 | 331 | 13 | 176 | 6.93 | 214 | 8.43 | 218 | 8.59 | 34 | 74.9 | F12 |
| NPH12-520W | 12 | 138 | 520 | 342 | 13.5 | 172 | 6.77 | 273 | 10.8 | 277 | 10.9 | 44 | 97 | F12 |
